DC 100V 50A Voltmeter & Ammeter
Features:
The fixed setpoint shunt is a suitable the attached external shunt for measuring DC current in 10kA less directly acting on the analog display instrument, together with the use in order to expand the scope of the DC current measurement, or sequentially circuit can be regarded as the current sampling with the standard resistors, a sampling voltage is measured with a current can be regarded as an analog signal.
Description:
1.Accuracy level :2-4000A, 0.5 level;5000-10000A, 1 level.
2.Environmental conditions: -40 ~ +60 °, with the relative temperature ≤ 95% (35 ° C)
3.Overload performance: 120% of rated current, 2 hours (around 120A max for 2 hours)
4.Voltage drop: 75mV
5.Load heat: Temperature rise changes stabilized, rated current of 50A does not exceed 80 ° C; rated current of 50A does not exceed 120 ° C.
Weight: 72g
Dimension (L x W x H): (Approx.) 12cm x 2.6cm x 1.8cm
DC 100V 50A Voltmeter & Ammeter
Specifications:
Working voltage of Meter itself:DC 4 - 30V(The maximum input voltage can not exceed 30V. Otherwise the meter will overload)
Working current of Meter itself:≤20mA
Voltage Measuring range: DC 0 - 100V
Current Measuring range: DC 0 - 50A
Voltage resolution (V): 0.1V
Current resolution (A): 0.01A
Measure accuracy: 1% (± 1 digit)
Display: 0.28" digital tube
Refresh rate: about 300mS / times
Dimensions:48mm*29mm*26mm
Operation Temp: -10°-+65°
Package Include:
1 x Dc 100v 50a Digital Voltmeter Ammeter Volt Amp Meter Voltmeter Ampermeter + 50A75mV FL-2 50A 75mV Shunt Voltmeter Car Module
