Model: CBB60
45uF, 500V AC Start/Run Capacitor (CBB60) With Lead Wires
Commonly used as a Start/Run Capacitor in Air Conditioners, Ceiling Fans, Ventilation Equipment, Air Conditioning
Standards | IEC 252:1993,EN60252:1994,UL810 |
Dielectric: | Polypropylene film |
Plates: | Zn/Al layer deposited by evaporation under vacuum |
Climatic Category | 25/70/21 |
Capacitance range | 12µF to 100µF |
Capacitance Tolerance | J(±5%), K(±10%) |
Rated Voltage(VAC) | 250V,400V,450V,500V,630V |
Withstand Voltage(VDC) | 2.0Ur (2S), 1.75Ur (5S) |
Max Voltage | 10% Variance of Rated Voltage |
Max Current | 10% Variance Rated Current |
Safety class | P0 |
Rated frequency(Hz) | 50/60 Hz |
Dissipation factor (20 ° C +/- 5 ° C) | Max.0.0020(120 Hz) |
Max.dv/dt(V/us) | 15 |
Test voltage terminal to case | 2000 Volt AC for 2 Seconds |
Casing | Plastic Case, Resin Filled |
Flame retardant character | Conforms to class UL94-0 |
Insulation Resistance | > 3000 M Ohm µF (20°C, 60S) |
Endurance(85°C,1.25Ur) | Class A 30,000 Hours 250VAC |
Class B 10,000 Hours 400VAC | |
Class C 3,000 Hours 450VAC |
