Worm Drive Gearbox to Suit Industrial Motors

$142.68 (Inc GST)
Weight: 1.800 kg
MCPG10010
+
Worm Drive Gearbox

Available in 12.1:1, 25:1, 50:1, 60:1 and 75:1 Ratios

High Quality Industrial Right or Left Angle Gearboxes



PLEASE NOTE THAT DUE TO A LABELING ERROR, SOME OF THE GEARBOXES ARE LABLED INCORRECTLY

RIGHT ANGLE IS AS PICTURED IN THE PICTURES OF THE GEARBOX.

These motors are a direct replacement for the gearbox on the 200W & 320W motors, used in our Industrial worm drive motors.
They are also a universal for for most other wormdrive motors in this range, so chances are that if your motor and gearbox are similar in looks to this one, the gearbox will be interchangeable.

If you are keen, its easy to convert this worm drive gearbox to a left angle drive. You need to pop the rivets out (with a long thin punch), split the gearbox apart, remove the key that holds the shaft on the main pinion wheel, then tap the shaft out, then change the shaft to the other side, re-fit the key and viola! Left angle drive! If you didn't damage the rivets you can reuse them just by using a tool to re-flare the ends. Alternatively, you can just use bolts.

Please note: These are provided as a gearbox only and do not come with any couplings.
